3 Axial-Plunger Wobble-Plate Pump: An optimized pump structure that ensures stable water output and minimizes mechanical wear.
Tempered Stainless Steel Plungers: These heat-treated plungers offer superior wear and corrosion resistance, significantly extending the life of the pump head.
Total Stop System (TSS): The machine automatically shuts off when the trigger is released. This saves energy, conserves water, and prevents the motor from overheating.
Quick-Connect System: All accessories feature a tool-free quick-connect design, allowing for assembly and disassembly in seconds.
Ergonomic Portable Design: Featuring an integrated heavy-duty top handle and a compact frame, the unit is easy to move with one hand and simple to store.
Product Advantages
Whisper-Quiet Durability: Unlike cheaper alternatives, the JZ506's induction motor reduces operational noise significantly while maintaining thermal stability during long cleaning sessions.
Eco-Friendly Efficiency: Using only $6.5-7.5$ liters of water per minute, it provides up to 100bar of stripping power—cleaning several times faster than a standard garden hose while using less water.
Weather-Resistant Build: Engineered with precision-sealed circuits and a rugged pump body to ensure safe operation in various climates and environments.
RATED PRESSURE (BAR) | 70 |
MAX PRESSURE (BAR) | 100 |
RATED FLOW (L/MIN) | 6.5 |
MAX FLOW (L/MIN) | 7.5 |
MOTOR POWER (W) | 1300W/1500W |
MOTOR TYPE： | INDUCTION MOTOR |
VOLT. / FREQ： | AC220-240V~50/60HZ AC120-127V~50/60HZ |
Automotive Care: Effortlessly remove road salt, stubborn brake dust from rims, and mud from the undercarriage.
Home Maintenance: High-efficiency cleaning for patio moss, oil stains on stone driveways, and dust on exterior walls.
Garden Equipment: Quickly blast away caked-on mud from lawnmowers, shovels, and outdoor furniture.
HVAC Cleaning: With the adjustable nozzle, it is safe and effective for professional cleaning of air conditioning condenser coils.
"Power in a Compact Box!"
"I was surprised by how quiet the induction motor is. It’s perfect for washing my pickup on Saturday mornings without waking the neighbors. Plenty of pressure to strip oil off the concrete."
— Michael S., Germany
"Reliable Business Partner."
"We use this as a backup unit for our small cleaning service. Its portability is a huge plus, and the Total Stop System is very responsive, protecting the motor perfectly."
— Agnes L., Poland
Q: Can I use warm water with this machine?
A: We recommend an inlet water temperature of no more than 40°C to protect the internal seals of the pump.
Q: Can it draw water from a bucket or tank?
A: The JZ506 is designed for use with a pressurized water source (tap). If you require self-priming capabilities, please contact our technical team for compatible accessories.
Q: Why is an induction motor better than a universal motor?
A: Induction motors have no carbon brushes to wear out, run much quieter, and are designed for continuous, heavy-duty use.
