Precision Wobble-Plate Pump Technology: The 3-axial plunger design offers a more compact structure with direct power transmission. This ensures minimal pressure fluctuation and a consistent, steady high-pressure water stream.
Tempered Stainless Steel Plungers: The plungers undergo specialized heat treatment for extreme hardness. This provides superior resistance to wear and rust, ensuring a long operational life even with varying water qualities.
TSS (Total Stop System): The motor automatically shuts off when the spray gun trigger is released and restarts instantly when squeezed. This saves energy, protects the motor, and extends the life of the pump seals.
Quick-Connect Accessory System: All components—including the gun, nozzles, and hoses—feature a tool-free quick-connect design. Assembly takes only seconds.
Product Advantages
Long-Term Durability: By combining a brushless induction motor with tempered stainless steel plungers, the JZ504 is built to outlast standard universal motor washers, making it ideal for daily professional tasks.
Comprehensive Accessory Kit: Comes standard with a high-performance gun body, short nozzle, extension pole, 5-meter high-pressure hose, and a precision filter head. It is ready for work right out of the box.
Superior Mobility: Designed with an ergonomic top handle and optimized center of gravity, allowing users to move between job sites with minimal effort.
Wide Voltage Adaptation: The specialized circuit design handles voltage and frequency variations with ease, making it the preferred choice for global distribution and cross-border trade.
RATED PRESSURE (BAR) | 70 |
MAX PRESSURE (BAR) | 100 |
RATED FLOW (L/MIN) | 6.5 |
MAX FLOW (L/MIN) | 7.5 |
MOTOR POWER (W) | 1300W/1500W |
MOTOR TYPE： | INDUCTION MOTOR |
VOLT. / FREQ： | AC220-240V~50/60HZ AC120-127V~50/60HZ |
Precision Auto Detailing: Use the short nozzle and extension pole to reach difficult angles like wheel wells, undercarriages, and engine bays.
Exterior Restoration: The 100-bar output easily blasts away stubborn moss, grime, and years of buildup from stone paths and brick walls.
Industrial Maintenance: Perfect for cleaning small agricultural machinery, factory conveyors, ventilation systems, and other industrial parts.
Property Management: Rapidly refresh wooden fences, stone sculptures, and swimming pool perimeters for a professional finish.
"The stainless steel plungers make a difference!"
"We used to deal with plastic pump heads that leaked after six months. The JZ504’s stainless steel plungers are incredibly stable. Even under high-intensity use, it performs flawlessly. JUZOR’s Professional Series is the real deal."
— Distributor from Argentina
"Highly efficient setup."
"The quick-connect design saves so much prep time. The induction motor is very quiet, allowing us to work in residential neighborhoods without noise complaints."
— Property Maintenance Manager
Q: Why is the "Wobble-Plate Pump" emphasized for the JZ504?
A: This structure strikes the perfect balance between efficiency and reliability. Compared to standard piston pumps, it has fewer moving parts, reducing the failure rate while providing a more uniform pressure output.
Q: What is the benefit of Tempered Stainless Steel Plungers?
A: The tempering process hardens the steel to resist scratches from water impurities. This prevents internal leaks in the pump chamber that typically lead to pressure loss over time.
Q: Can this machine handle hot water intake?
A: We recommend an inlet water temperature of no more than 40°C (104°F) to maintain the optimal condition of the pump’s seals.
Q: Do you provide spare parts for the JZ series?
A: Yes. As the manufacturer, we provide a full supply chain for accessories, technical manuals, and repair kits to support your long-term business.
