Axial-Plunger Wobble-Plate Pump: Optimized pump structure ensures stable pressure output while significantly reducing vibration during operation.
Tempered Stainless Steel Plungers: Crafted from high-strength, wear-resistant materials to dramatically extend pump life and prevent internal corrosion.
Total Stop System (TSS): The motor automatically shuts off when the spray gun trigger is released. This saves energy, prevents pump overheating, and prolongs the motor’s lifespan.
Portable Design with Handle: Features an ergonomically designed top handle, allowing for easy one-handed mobility and flexible operation across various job sites.
Quick-Connect Accessories: Equipped with standardized quick-connect interfaces for tool-free assembly, saving you time and effort on every job.
Product Advantages
Quiet Induction Motor: Compared to traditional universal motors, the JZ502's induction motor is quieter, smoother, and requires zero carbon brush maintenance.
Compact Powerhouse: With a peak pressure of 100 Bar, it handles most residential and semi-professional cleaning tasks with ease, yet remains small enough to store in a car trunk or utility closet.
High Water Efficiency: While providing massive cleaning power, the JZ502 uses approximately 70% less water compared to a standard garden hose.
RATED PRESSURE (BAR) | 70 |
MAX PRESSURE (BAR) | 100 |
RATED FLOW (L/MIN) | 6.5 |
MAX FLOW (L/MIN) | 7.5 |
MOTOR POWER (W) | 1300W/1500W |
MOTOR TYPE： | INDUCTION MOTOR |
VOLT. / FREQ： | AC220-240V~50/60HZ AC120-127V~50/60HZ |
Vehicle Detailing: Easily removes stubborn mud and grime from cars, motorcycles, and bicycles.
Home Maintenance: Rapidly cleans patios, fences, steps, and dust-covered windows.
Garden Care: Perfect for cleaning garden tools, outdoor furniture, and removing moss from stone pathways.
HVAC Cleaning: Ideally suited for rinsing AC condenser fins to improve heat exchange efficiency.
"Power beyond expectations!"
"I bought the JZ502 for car washing and the pressure is fantastic. The induction motor is incredibly quiet. Most importantly, it's so compact—it fits perfectly in the corner of my tight garage."
— David L. (UK)
"Durable Professional Equipment"
"As a cleaning contractor, I needed a durable, small backup machine. The stainless steel plungers on the JZ502 really hold up; it ran for an hour straight without overheating. Highly recommended!"
— Mark S. (Germany)
Q: Does the JZ502 support self-priming (suction from a bucket)?
A: Yes, it supports both tap water pressure and self-priming from a bucket (we recommend using the included filter head to prevent debris from damaging the pump).
Q: Is the maintenance for this machine complicated?
A: Not at all. Thanks to the brushless induction motor, it is virtually maintenance-free. Simply drain any remaining water from the pump after use and periodically check the inlet filter.
Q: Can I use hot water with this unit?
A: We recommend an inlet water temperature not exceeding 40°C to protect the internal seals.
